Electrical Specifications for Microphone Section
|
||
|
Item
|
Value
|
|
|
Type and Dimension
|
Condenser Type, Dimension =Φ6.0×5.0mm
|
|
|
Output Impedance
|
 2.2KΩ±10%
|
|
|
Sensitivity
|
 -40dB±2dB
|
|
|
Frequency Range
|
 50Hz~10KHz
|
|
|
Directivity
|
 Omni-directional
|
|
|
Operation Voltage
|
Standard Voltage 2V
Max. Operation Voltage 10V |
|
|
S/N Ratio
|
More Than 58dB
|
|
|
Electrical Specifications for Speaker Section Item Value Conditions
|
||
|
Item
|
Value
|
Conditions
|
|
Speaker Dimensions
|
Φ14.8×4.4 mm
|
|
|
Impedance
|
32 Ω±15%
|
(At 1.0KHZ/1.0V)
|
|
Rated Input Power
|
0.3W
|
|
|
Max. Input Power
|
0.5W
|
|
|
Sensitivity
|
117dB±3dB
|
|
|
Frequency Response
|
0HZ~10KHZ
|
Average SPL-10dB
|
|
Distortion
|
 10 %Max
|
At 1.0KHZ/1.0mW
|
